- Endurance Gravel BIKES -
Diverge 4 Sport
Ride it Risk-Free for 30 Days!
Every bike comes with our 30-Day Ride Guarantee. Take it home, ride it like you own it. If it’s not right, bring it back within 30 days & we’ll refund your purchase or help you find the right bike.
Normal wear and tear is expected because the only way to know it’s the right ride is to ride it.
Overview
Race-tuned. Adventure-approved. The Diverge 4 gravel bike is built for full-gas race days and off-grid epics. With Future Shock 3.0, our most responsive frame ever, massive tire clearance, and the biggest internal storage in gravel, the best gravel bike in the world just got better. Chase the horizon—or your rivals—it’s built for both.
Features
About the Diverge 4 Sport
The Build Specs
Frameset
| Frame | Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout |
|---|---|
| Fork | Future Shock 3.1 w/ Smooth Boot, FACT 9r Carbon 12x100mm, thru-axle, flat-mount disc |
Brakes
| Front Brake | Shimano GRX BR-RX410 Hydraulic Disc |
|---|---|
| Rear Brake | Shimano GRX BR-RX410 Hydraulic Disc |
Drivetrain
| Bottom Bracket | Shimano BSA Threaded 68mm |
|---|---|
| Crankset | Shimano GRX FC-RX610, 40t |
| Rear Derailleur | Shimano GRX RX822, 12-speed |
| Cassette | Shimano SLX, CS-M7100, 12-speed, 10-51t |
| Chain | Shimano SLX CN-M7100, 12-speed |
| Shift Levers | Shimano GRX ST-RX610 12-speed |
Wheels & Tires
| Front Wheel | DT Swiss G540 700c, Center Lock Disc |
|---|---|
| Rear Wheel | DT Swiss G540 700c, Center Lock Disc |
| Inner Tubes | Presta, 700x32-50mm |
| Front Tire | Tracer TLR All Terrain Gravel Tire 700x45, Tan Sidewall, Tubeless Ready |
| Rear Tire | Tracer TLR All Terrain Gravel Tire 700x45, Tan Sidewall, Tubeless Ready |
Cockpit
| Saddle | Body Geometry Power Sport, steel rails |
|---|---|
| Seatpost | Carbon, single-bolt, 27.2mm |
| Stem | Future Stem, Comp |
| Handlebars | Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare |
| Seat Binder | Specialized Alloy, 30.8mm |
| Tape | Supacaz Super Sticky Kush |
Accessories
| SWAT | SWAT 4.0 internal downtube storage |
|---|
Weight
| Weight Size | 56 |
|---|---|
| Weight | 9.79 kg (21 lb, 9.3 oz) |
The Geometry
| Measurement | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Stackmm | 563 | 578 | 592 | 610 | 634 | 659 |
| Reachmm | 365 | 374 | 387 | 400 | 412 | 425 |
| Head Tube Lengthmm | 90 | 104 | 116 | 135 | 161 | 187 |
| Head Tube Angledegrees | 70 | 70.5 | 71 | 71 | 71 | 71 |
| BB Dropmm | 85 | 85 | 85 | 85 | 85 | 85 |
| Trailmm | 72 | 68 | 65 | 65 | 65 | 65 |
| Fork Length, Fullmm | 391 | 391 | 391 | 391 | 391 | 391 |
| Fork Rake/Offsetmm | 55 | 55 | 55 | 55 | 55 | 55 |
| Front Centermm | 604 | 613 | 626 | 645 | 665 | 686 |
| Chainstay Lengthmm | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbasemm | 1019 | 1031 | 1041 | 1060 | 1081 | 1102 |
| Top Tube Length, Horizontalmm | 521 | 537 | 556 | 575 | 593 | 613 |
| Bike Standover Heightmm | 700 | 725 | 754 | 779 | 805 | 832 |
| Seat Tube Lengthmm | 400 | 430 | 470 | 500 | 530 | 560 |
| Seat Tube Angledegrees | 74.5 | 74 | 74 | 74 | 74 | 74 |
