- Endurance Gravel BIKES -
1/9
Diverge 4 E5 Comp
$2,699.99
Ride it Risk-Free for 30 Days!
Every bike comes with our 30-Day Ride Guarantee. Take it home, ride it like you own it. If it’s not right, bring it back within 30 days & we’ll refund your purchase or help you find the right bike.
Normal wear and tear is expected because the only way to know it’s the right ride is to ride it.
Overview
Diverge 4 Alloy
The Ultimate Getaway Vehicle
Race-tuned. Adventure-approved. The Diverge 4 gravel bike is built for full-gas race days and off-grid epics. With Future Shock 3.0, our most responsive frame ever, massive tire clearance, and internal storage for the first time ever on an alloy bike, the best gravel bike in the world just got better. Chase the horizon—or your rivals—it’s built for both.
Features
Use
Gravel Adventure/Race
Frameset
E5 Premium Alloy
Suspension
Future Shock 3.1
Drivetrain/Wheels
SRAM Apex Eagle 1x12 / DT G540
Storage
SWAT 3.0
Weight
Diverge Alloy Comp: 10.6kg
About the Diverge 4 E5 Comp
The Build Specs
Frameset
| SWAT | SWAT 3.0 internal downtube storage |
|---|---|
| Frame | Specialized Diverge E5 Premium Aluminum, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout |
| Fork | Future Shock 3.1 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc |
Brakes
| Front Brake | SRAM Apex, Hydraulic disc |
|---|---|
| Rear Brake | SRAM Apex, hydraulic disc |
Drivetrain
| Crankset | SRAM Apex DUB Wide, 40t |
|---|---|
| Rear Derailleur | SRAM Apex Eagle 12-speed |
| Bottom Bracket | SRAM DUB BSA 68 Wide |
| Chain | SRAM NX Eagle, 12-speed |
| Cassette | SRAM PG-1210 Eagle, 12-speed, 11-50t |
| Shift Levers | SRAM Apex |
Wheels & Tires
| Front Wheel | DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples |
|---|---|
| Rear Wheel | DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples |
| Inner Tubes | Presta, 700x32-50mm |
| Front Tire | Tracer TLR All Terrain Gravel Tire 700x45, Tubeless Ready |
| Rear Tire | Tracer TLR All Terrain Gravel Tire 700x45, Tubeless Ready |
Cockpit
| SeatPost | Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware |
|---|---|
| Seat Binder | Alloy, 30.8mm |
| Saddle | Body Geometry Power Sport, steel rails |
| Stem | Future Stem, Comp |
| Handlebars | Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare |
| Grips | Supacaz Suave |
Weight
| Weight | 10.6 kg (23 lb, 5.9 oz) |
|---|---|
| Weight Size | 56 |
The Geometry
| Measurement | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Stackmm | 563 | 578 | 592 | 610 | 634 | 659 |
| Reachmm | 365 | 374 | 387 | 400 | 412 | 425 |
| Head Tube Lengthmm | 90 | 104 | 116 | 135 | 161 | 187 |
| Head Tube Angledegrees | 70 | 70.5 | 71 | 71 | 71 | 71 |
| BB Dropmm | 85 | 85 | 85 | 85 | 85 | 85 |
| Trailmm | 72 | 68 | 65 | 65 | 65 | 65 |
| Fork Length, Fullmm | 391 | 391 | 391 | 391 | 391 | 391 |
| Fork Rake/Offsetmm | 55 | 55 | 55 | 55 | 55 | 55 |
| Front Centermm | 604 | 613 | 626 | 645 | 665 | 686 |
| Chainstay Lengthmm | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbasemm | 1019 | 1031 | 1041 | 1060 | 1081 | 1102 |
| Top Tube Length, Horizontalmm | 521 | 537 | 556 | 575 | 593 | 613 |
| Bike Standover Heightmm | 700 | 725 | 754 | 779 | 805 | 832 |
| Seat Tube Lengthmm | 400 | 430 | 470 | 500 | 530 | 560 |
| Seat Tube Angledegrees | 74.5 | 74 | 74 | 74 | 74 | 74 |
